         FEATURED PRODUCT
Jackson Systmes - Zone Control Made Simple

WCZ-600 Wireless Comfort™ Zone Panel
Retrofit Zoning Made Simple

The WCZ-600 Wireless Comfort™ zone control system is a six zone, two-position, forced air zone control panel offering the latest in wireless thermostat and wireless damper technology to greatly reduce installation time and labor costs.

WIRELESS Communication between THERMOSTATS and DAMPERS saves you time on every installation.



WCZ-600 Wireless Comfort™ Zone Panel[click to enlarge]

BENEFITS:

-

 Eliminates costly installation of wiring thermostats and dampers.

-

 Allows contractors to offer zoning in applications once thought impossible to install.

-

 Universal control for single stage, multi-stage, heat pump and dual fuel systems (up to 4 heat / 2 cool).


FEATURES:

-

 PDM (Programming Display Module) guides the installer through all setup options.

-

 Wireless 915MHz proprietary protocol with up to 100 feet transmission range for thermostats and dampers.

-

 LEDs show zone and panel status.
- Redundant safety features protect equipment and maintain heating and cooling temperatures in the event of communications failure.
- 5 year warranty.


SPECIFICATIONS:
-Compatible Equipment: Single stage, multi-stage, heat pump, dual fuel (4 heat / 2 cool)
-System Terminals: RH, RC, W1, W2, Y1, Y2, G, DS/BK, O, B
-Fan Operation: Gas or electric
-LED Indication: Status for all zone and panel functions
-Communication: Wireless, 915MHz, proprietary protocol
-Range: Up to 100 feet
-Panel Power: 24VAC, 40VA
-Panel Dimensions: 6” x 8” (W x H)
-Panel Enclosure Dimensions: 7” x 8” x 1.5” (W x H x D)



WCZ-600 Wireless Comfort™ Zone Panel by Jackson SystemsDownload Literature:

WCZ-600 Wireless Comfort™
Zone Control Panel


Made in
USA
